Bell 22F
Wi-Fi Wired Doorbell
Key Features
5 MP Wired Doorbell
4:3 aspect ratio
Two-way audio (full duplex), voice changer
Motion detection
Motion zone selection
Night visibility up to 10 m
Support wireless chime
Support WebRTC
Image Sensor
1 / 2.7'' 5 Megapixel CMOS
Effective Pixels
2592 (H) × 1944 (V)
Min. Illumination
Color 0.1 Lux @ F2.0
Black / White 0.01 Lux @ F2.0
IR Distance
Night visibility up to 10 m
Day / Night
Auto(ICR) / Color / B & W
WDR
DWDR
Lens(H / V / D)
3.2 mm @ F2.0, 105° / 75° / 140°
Compression
H.265
Bit Rate
32 Kbps ～ 2 Mbps
Frame Rate
1 ～ 25 fps
Dual Stream
Yes
Audio Input / Output
Built-in mic / speaker
Alarm Trigger
Button triggering, motion detection
Communication Protocol
HTTP, TCP / IP, DHCP, DNS, RTSP
Interface Protocol
Private
Wireless
2.4 GHz Wi-Fi (IEEE802.11 b / g / n)
Mobile Phone OS
iOS 9 or later, Android 5 or later
Security
AES128
Operating Temperature
-10 °C ～ 50 °C
IP Rating
IP65
Power Supply
AC 8 ～ 26 V, DC 5 V / 1 A
Consumption
Up to 2.5 W
Storage
TF card(Up to 256 GB), Cloud storage, NVR
Dimensions
46 × 38 × 137 mm
Net Weight
130 g
