Snap 30T
Wi-Fi Outdoor PTZ Battery Camera
Key Features
Color night vision
Support Bluetooth pairing
Support local AI human detection
Auto tracking
Support TF card (up to 256 GB) storage
Two-way audio (half duplex)
Support P/T function
100% wire-free
5200 mAh rechargeable batteries
Support powered by solar panel
Image Sensor
1 / 2.9'' 3 Megapixel CMOS
Max. Resolution
2304 (H) × 1296 (V)
Shutter
1 / 15 ～ 1 / 10,000 s
Min. Illumination
Color 0.1 Lux @ F2.4
Black / White 0.01 Lux @ F2.4
IR Distance
Up to 10 m
Day / Night
Auto (ICR) / Color / B & W
WDR
DWDR
Lens & FOV (H / V / D)
3.6 mm @ F2.4，85° / 50° / 100°
Compression
H.264
Bit Rate
32 Kbps ～ 2 Mbps
Frame Rate
1 ～ 20 fps
Dual Stream
Yes
Audio Input / Output
Built-in mic
Wireless Security
64 / 128-bit WPA / WPA2，WPA-PSK / WPA2-PSK / WPA3-PSK，WPS
Communication Protocol
HTTP, DHCP, DNS, TCP / IP
Interface Protocol
Private
Wireless
2.4 GHz Wi-Fi (IEEE 802.11 b / g / n / ax)
Mobile Phone OS
iOS 9 or later, Android 5 or later
Security
AES128
Max. User Access
4
Capacity
5200 mAh rechargeable Li batteries
Stand-by Current
200 ～ 800 µA (average)
Working Current
150 ～ 200 mA (IR off)
Stand-by Time
6 months
Working Time
1.5 ～ 2.5 months (10 times wake-up per day)
PIR Detection Range
Up to 9 m
PIR Angle
120°
Pan/Tilt
Pan: 0° ～ 340°，Tilt: -90° ～ 0°
Operating Temperature
-20 °C ～ 60 °C
Weather Resistance
IP54
Power Supply
DC 5 V / 1 A
Power Consumption
Up to 2 W
Alarm Trigger
Motion detection
Ports
Type-C *1
Storage
TF card (up to 256 GB)，Cloud storage
Dimensions
170 × 123 × 150 mm
Weight
550 g
