Mini 7Q
Wi-Fi Indoor Camera
Key Features
4 MP Indoor Fixed Camera
Intelligent motion / sound detection
Motion zone selection
Two-way audio (half duplex)
Night visibility up to 10 m
Support TF card (up to 256 GB) / Cloud storage
Support WebRTC
Image Sensor
1 / 3'' 4 Megapixel CMOS
Effective Pixels
2560 (H) × 1440 (V)
Min. Illumination
Color 0.1 Lux @ F2.0
Black / White 0.01 Lux @ F2.0
Lens(H / V / D)
3.6 mm @ F2.0, 82° / 45° / 95°
Day / Night
Auto(ICR) / Color / B & W
IR Distance
Night visibility up to 10 m
WDR
DWDR
Compression
H.264
Bit Rate
32 Kbps ～ 2 Mbps
Frame Rate
1 ～ 25 fps
Dual Stream
Yes
Audio Input / Output
Built-in mic / speaker
Alarm Trigger
Intelligent motion / sound detection
Communication Protocol
HTTP, DHCP, DNS, TCP/IP, RTSP
Interface Protocol
Private
Wireless
2.4 GHz & 5 GHz Wi-Fi (IEEE802.11 b / g / n / ac / ax)
Mobile Phone OS
iOS 9 or later, Android 5 or later
Security
AES128
Operating Temperature
−20 °C ～ 50 °C
Power Supply
DC 5 V / 1 A
Consumption
Max.2.5 W
Storage
TF card(Up to 256 GB), Cloud storage
Dimensions
53 × 51 × 113 mm
Net Weight
50 g
